Core item | Detailed parameter index |
bare weight | 116g |
Whole machine weight | 160g(Including18650 rechargeable battery) |
Material | aluminum alloy |
Color | black |
Helmet stents | 98g microarc oxidation ,Subsurface treatment |
Standby time | 36 h(Non-infrared) 24 h(Infrared) |
Full length of bare machine | 6.6cm |
Night vision effective distance | Over 300m (all black) |
Infrared wavelengths | 980nm (no red storm) |
Infrared working mode | ü Infrared closed ü Low power infrared mode ü medium power infrared mode ü high power infrared mode |
Image sensor | 1/1.9'WYX185C-MM |
View of angle | 39.5° |
Focus distance | 12.5cm-infinite |
Machine core voltage | 2.4V~5.5V Start and work normally undervoltage |
power consumption of the movement | 0.9w |
OLED screen resolution ratio | 1024*768P(Display clearly at night, distinguish enemies effectively) |
Pixel size | 6um*6um |
minimum illumination at night | 0.0013lux(Black and white image) |
display size | 0.38inch screen |
Display brightness | Adjustable 9 stalls to adjust screen brightness |
Working temperature | 45ºC~70ºC (military level) |
Waterproof level | IPX6 |
installation | Hand-held, also suitable for various helmets right eye observation at night. |
System package | night warfare system(1 PCS) 2 set of special battery 1 set of special charger 1 special data cable 1 special plug 1 set of factory certificate 1 set of professional tactical helmet 1 set of soft helmet 1 set of universal helmet bracket 1 pcs waterproof tank |
warranty way | Global co-insurance for 2 years. |
packing way | Water proof box waterproof carton packing |
